60LEDS

  TOP SMD3535 or SMD5050 chip, high brightness, low decay.

  Integrated internal control chip.

  DC5V or DC12V drive, safe usage.

  Thick 2oz~3oz copper PCB for excellent thermal management.

  Available in IP20,IP65,IP66,IP67,IP68.

  3M adhesive backing.

  Low power consumption, long life span, free maintenance.


Technical Data

TECHNICAL DATA

LED ChipRGB3535/RGB5050
IC ControlSK6812/WS2812
IP classificationIP20/IP65/IP67/IP68

Input Voltage

DC5V/DC12V

Strip PowerMax. 28.8W/M
Maximum quantity per power input5 meters
Average lifetime30,000 hour
Color temperatureRGB
Operating temperature-20° C till +50° C
PCB Width10 mm
min. Bending radius20 mm
LED QTY/M300 Leds/Meter
CuttableAll 6 LEDs (2 cm)
CRI85~95
Warranty3 Years
